2022-2018 FORD MUSTANG GT (5.0 4V)
OVER 315 CRANK HP GAIN THAT YOU CAN BOLT ON IN THE GARAGE!
It’s still hard to believe that our Mustang supercharger systems can deliver more Hp increase than the total HP a stock Mustang GT left the factory with a decade ago. Now that is progress!
The Coyote 5.0L is an incredible engine with incredible potential. This engine utilizes Variable Valve Timing and aggressive spark calibration (with spark knock sensors), which allows the engine to constantly push itself to its potential. Factory Hp is a rock solid 460Hp at the crank, and we build on that firm foundation with performance upgrades that go beyond a Horsepower increase of 70%+ (approaching 800 total Crank HP!).
| DESCRIPTION | BOOST | HP GAIN | PART # | EO # |
|---|---|---|---|---|
| HO Intercooled System with Factory Airbox and P-1SC-1 | 6.5 psi | 55-60%+ | 1FW611-SCI | D-365-31 |
| HO Intercooled Tuner Kit with Factory Airbox and P-1SC-1 | specify | specify | 1FW601-SCI | - |
| HO Intercooled System with P-1SC-1 | 6.5 psi | 55-60%+ | 1FW614-SCI | - |
| HO Intercooled Tuner Kit with P-1SC-1 | specify | specify | 1FW604-SCI | - |
| Stage II Intercooled System with Factory Airbox and P-1SC-1 | 8.5 psi | 65-70%+ | 1FW613-SCI | D-365-31 |
| Stage II Intercooled Tuner Kit with Factory Airbox and P-1SC-1 | specify | specify | 1FW603-SCI | - |
| Stage II Intercooled System with P-1SC-1 | 8.5 psi | 65-70%+ | 1FW612-SCI | - |
| Stage II Intercooled Tuner Kit with P-1SC-1 | specify | specify | 1FW602-SCI | - |
Note: HO and Stage II Tuner Kits (with Factory Airbox) use a 6 rib shared belt drive.
Tuner Kits: These kits make sense for someone wanting to perform custom tuning of the car and push the envelope in performance. Will most likely be experimenting with alternative fuels such as 93 octane, race fuel, E85 fuel, and methanol supplemental fuel. In addition, possibly changing engine components like heads, headers, exhaust, and cams for the engine. No tuning or fuel components provided.
Want to learn about HO vs. Stage II, Tuner Kits vs. Systems, Intercooling tech and much more? Click the button below to visit the ProCharger 101 page.
WHAT'S INCLUDED:
– HO System:
- Shared 6 rib supercharger belt drive system
- OEM quality bolt-on design and finish
- Belts can be changed without removing supercharger
- Pulleys can be changed without removing supercharger
- Tuning setup provided, including handheld tuner
- Easy install with common hand tools
- No cutting required, 100% bolt on and reversible
– Stage II System:
- Same as HO system plus additions below:
- 65-70% Hp gain on pump gas with 8.5 psi boost
- 75% larger intercooler 1,103 sq in. core
- 8-rib dedicated belt drive system for maximum power transfer
OPTIONS
For both our Complete Systems and Tuner Kits, we offer more options than any competitor and give you the chance to customize your system or kit the way you want it.
- Polished, Black or Satin Supercharger finish
- Polished, Black or Satin Bracket finish
- Black intercooler finish
- Helical Gear set for Noise Reduction (P-1SC-1 & D-1SC only)
- P-1SC-1 up to F-1A-94 head units available
- Standard HO or Stage 2 Air-to-Air Intercooler
- Race Bypass Valve upgrade (for cars over 750HP, or those that want a loud bypass)
From Street to Track
No matter if you are running a low boost street system, or looking to set records at the track, the ProCharger Stage 2 system delivers. One case example is the street-driven Mustang GT owned by Nick Fosnaugh. This cars 7-second track results come thanks to the very same bracket, tensioner, and belt system that all our Stage 2 customers receive in their kits, combined with a F-1A-94 head unit. Nick opted for our CrankSupport due to the high HP and RPM of his combination.
P-1X / D-1X Upgrade
The ProCharger P-1X and D-1X head units feature the robust, self-contained gearcase that is standard on most ProCharger models, but with a new aerodynamic compressor design that creates cooler charge air temperatures and more horsepower at the same boost level than our industry-standard P-1SC-1 and D-1SC. This higher efficiency design was engineered to be a bolt-in replacement for P-1SC-1 and D-1SC equipped systems and has even greater max-power potential.
BIGGER IS BETTER
Our Stage II system includes a fuel system upgrade and our higher performance intercooler, over 75% larger than our HO intercooler, ensuring your air charge will be at its lowest temperature before entering the throttle body. Our engineers have designed this system for a capable DIY’er making it easy to install while still delivering monster power numbers requiring no fabrication at all!
IMAGINE YOURSELF INSTALLING IT IN YOUR OWN GARAGE!
Thanks to the guys over at Muscle Mustangs and Fast Fords magazine, you don’t have to imagine it, you can read all about it. They have done a full step-by-step install of a Stage 2 ProCharger supercharger system from start to finish. And the numbers are big: 276 Rear Wheel HP (RWHP) gained or approximately 315 Crank HP – with an otherwise stock 2018 Mustang, running only 8.5 psi with the Stage 2 system and 93 octane pump gas. That’s more than the total HP from a Mustang Cobra just a few decades ago!
This installation is simple and something one can perform using common hand tools over the weekend. And the best part is not a single piece of your new Mustang needs to be modified to make this system work. That means no cutting, bending, trimming, grinding, etc.
Mustang 360 Article
This installation is simple and something one can perform using common hand tools over the weekend. And the best part is not a single piece of your new Mustang needs to be modified to make this system work. That means no cutting, bending, trimming, grinding, etc. Don’t take our word for it, just click the button below to read the article.
FIND A DEALER NEAR YOU
Looking to make a purchase or a shop to install? We have a large group of dealers ready to serve you with your ProCharger needs. Click below to find a dealer near you!
BUILD & PRICE
Kits starting at $7,248. Pricing on these units vary by configuration. Configure your purchase now.
PLEASE NOTE: Pricing on this website reflects the June 30, 2022 Application Price Guide. No surcharges are currently in effect.
SPEAK WITH AN EXPERT
Click to call our sales staff or email us if you need any help. We will be happy to assist you with any questions you may have.
Mon – Fri 8am – 5:30pm CST
Phone – (913) 338-2886
Sales Email – [email protected]
INSTALL MANUAL
Get a Catalog
Our catalogs feature much of this detail. You can either download a copy or have one mailed to you free of charge.
CALIFORNIA EMISSIONS COMPLIANCE INFO (CARB)
Tuner kits for this vehicle are NOT legal for street use in California. These products are intended for racing or off road applications only. California approved products for street legal use (complete systems) will have an associated CARB EO# for compliance. For a full list of California and 50 state street legal systems, click below.
EMISSIONS COMPLIANCE
ProCharger offers Executive Orders for Emissions Compliance (EO) from California Air Resources Board (CARB) for many of our most popular car, truck and SUV applications. If you live in California, we can only sell you products with EO certification. Check out our full list of EO offerings.
